Self Closing Basin Mixer BS08212

Electronic Infrared Detection Basin Mixer, applications and advantages.

Electronic Infrared Detection Basin Mixer are fitted to domestic hot water installations (sinks) and allow action on a desired temperature. Depending on the model, the faucet will be battery operated and will be equipped with an infrared sensor.Chromed zamak main body and cover

• Bi-stable solenoid valve 6 V (internal)
• Infra-red sensor
• Hot water temperature lock system
• 6 V CRP2 lithium battery (internal)
• With check valves
• Stainless steel flexible hoses 1/2” with filters
• Flow rate 6 l/min
• Operating pressure : Min 1 - max 8 bar
• Water inlet temperature : 5 - 70 °C

Power supply : Lithium battery 6 V (included)

Thermostatic mixing valves, applications and advantages.

Thermostatic mixing valves are fitted to domestic hot water installations and allow action on a desired temperature. There are two types :

• ST : thermostatic mixing valve for supply point with mixed water at 38°C (adjustment range: 32-45°C) with blue adjustment ring.
• SE : thermostatic mixing valve for hot water distribution in the circulating loop > 55°C (adjustment range: 45-60°C) with red adjustment ring.

It is possible to change the direction of the mixed water outlet. Our mixers are equipped with an "anti-scald" safety mechanism. Equipment for 1 to 21 health posts.

Electronic Infrared Detection Basin Mixer with fixed spouts, applications and advantages.

Electronic Infrared Detection Basin Mixer with fixed spouts are fitted to domestic hot water installations (sinks) and allow action on a desired temperature. Depending on the model, the faucet will be battery operated and will be equipped with an infrared sensor.

• Chromed brass body
• Chromed brass fixed spout
• Bi-stable solenoid valve 6 V (internal)
• Infra-red sensor
• 6 V CRP2 lithium battery (internal)
• Stainless steel braided 1/2” flexible hoses and check valves
• Flow rate 6 l/min
• Operating pressure : Min 1 - max 8 bar
• Water inlet temperature : 5 - 70 °C

Power supply : Lithium battery 6 V (included)

Electronic Infrared Detection Basin Mixer, applications and advantages.

Electronic mixing valves with fixed spouts are fitted to domestic hot water installations (sinks) and allow action on a desired temperature. Depending on the model, the faucet will be battery operated and will be equipped with an infrared sensor.

• Chromed brass body
• Chromed brass fixed spout
• Bi-stable solenoid valve 6 V (internal)
• Infra-red sensor
• 6 V CRP2 lithium battery (internal)
• Stainless steel braided 1/2” flexible hoses and check valves
• Flow rate 6 l/min
• Operating pressure : Min 1 - max 8 bar
• Water inlet temperature : 5 - 70 °C

Power supply : Lithium battery 6 V (included)

Electronic Infrared Detection Basin Mixer, applications and advantages.

Infrared detection basin tap are fitted to domestic hot water installations (sinks) and allow action on a desired temperature. Depending on the model, the faucet will be battery operated and will be equipped with an infrared sensor.

• Chromed brass body
• Infra-red sensor
• Bi-stable solenoid valve with water connections G1/2” (external)
• Copper connecting pipe
• 4 alkaline batteries with water proof housing (external)
• Flow rate 6 l/min
• Operating pressure : Min 1 - max 8 bar
• Water inlet temperature : 5 - 70 °C

Power supply : 4 alkaline batteries (included)

Thermostatic mixing valves for domestic application water heater outlet, advantages

Mixing valves with brass body and metallic cartridge suitable for facilities producing solar heated domestic hot water, 1 OV20 valve, 1 OV20HT valve and orange cap. Flow rate 30L/mn - Temperature adjustment range 30 to 55°C Max. temperature = 110°C for the full mixer. Continuous resistance = 127°C for the OVHT valve (for hot water). Advantages :

• Anti-scalding and anti-legionella protection Increase in hot water autonomy
• Water saving
• Longevity of installations thanks to temperature adjustment

Key features :

• Solid brass construction EN CW617N standardMetallic cartridge with wax element
• Robust and compact
• Assembly and adjustment without any special tools
• Integrated filters and non-return valves



Self Closing Basin Tap, applications and advantages.

Sanitary fittings for public and commercial places: water savings, hygiene, comfort and design.

Sustainability

Automatic shut-off systems Flow rate control system.

Hygiene

No manual contact after the tap shuts off is required. This prevents the spread of germs by hands. Easy cleaning. The ergonomic design and the smooth surface, without breaks or gaps, allow cleaning the surfaces in a simple and effective way, preventing bacteria.

Safety and prevention

Anti-scalding safety system, which reduces and maintains the temperature of the water, ensuring safety without supervision. Vandal-resistant controls, preventing misuse, unwanted removal, willful damage.

Resistance

Suitable for intensive use.

Comfort and easy use

Reliability Our products are easy to install and they need minimal adjustments. Our products are easy to install and they need minimal adjustments. The spare parts are standardized to assure a quick and easy replacement.

Italian design

Modern, simple, ergonomic design

Self Closing Basin Tap, applications and advantages.

Self Closing Basin Tap are fitted to domestic hot water installations and allow action on a desired temperature.

• AISI 316L stainless steel tap brushed
• Push button control

Sanitary fittings for public and commercial places: water savings, hygiene, comfort and design.

Substainability

• Automatic shut-off systems
• Flow rate control system

Hygiene

• No manual contact after the tap shuts off is required. This prevents the spread of germs by hands.
• Easy cleaning. The ergonomic design and the smooth surface, without breaks or gaps, allow cleaning the surfaces in a simple and effective way, preventing bacteria.
• Anti-bacteria system. Automatic anti-legionella rinsing system: every 24 after the last use, an automatic flush activates for 7 seconds, preventing water stagnation that can cause the development of legionella

Safety and prevention

• Anti-scalding safety system, which reduces and maintains the temperature of the water, ensuring safety without supervision
• Vandal-resistant controls, preventing misuse, unwanted removal, willful damage

Resistance and reliability

• Suitable for intensive use.

Comfort and easy use

• Our products are easy to install and they need minimal adjustments. The spare parts are standardized to assure a quick and easy replacement.

Italian design

• Modern, simple, ergonomic design
